Description

SB7-HDG6 kit features ACT’s most popular Heavy Duty pressure plate. ACT Heavy Duty pressure plates use exclusive diaphragm design to increase clamp load, reduce deflection and maximize clutch life. All diaphragms endure a four-stage, heat-treating process for unparalleled performance. ACT pressure plates have precision cover stampings to provide rigidity and consistency. ACT’s 6-pad, spring-centered race disc features a spring-center to properly damp torsional vibrations and resist failure under harsh conditions. ACT spring retainers utilize wraparound spring windows and thicker retainer stampings to provide spring support, reduce stress concentrations, and increase strength and reliability. With the 6-pad, spring-centered race disc, engagement is harsher, but shifting is faster. The 6-pad, spring-centered disc is recommended for larger clutch sizes to absorb more heat.
HD/Race Sprung 6 Pad
Light to moderate pedal effort, aggressive engagement, OE to mild gear rattle; Moderate friction life, extended by ACT’s exclusive diaphragm design; Carefully engineered, precisely assembled, accurately balanced, uses select ceramic friction materials for high heat tolerance and maximum performance; Recommended for high horsepower street or race use; 100% clamp load tested and dynamically computer balanced for smooth high RPM reliability

Fitment:
2013 Scion FR-S
2013 Subaru BRZ
2014 Scion FR-S
2014 Subaru BRZ
2015 Scion FR-S
2015 Subaru BRZ
2016 Scion FR-S
2016 Subaru BRZ
2017 Subaru BRZ
2017 Toyota 86
2018 Subaru BRZ
2018 Toyota 86
2019 Subaru BRZ
2019 Toyota 86
2020 Subaru BRZ
2020 Toyota 86
